GN WELLHEAD ISOLATION TOOL
Wellhead Christmas Tree Bypass Tool
Overview
Preserve your everyday wellhead with GN’s wellhead isolation tool for high-pressure stimulation treatments. Our stress-tested isolation tool is manufactured per specific regulations, including API 6A, ANSI/NAC, MR0175, and DNV.
There’s no need to kill your well to install and use our isolation tool. Keep your
oil and gas operations on schedule while protecting your daily-use wellheads during well stimulation treatments.
CUSTOMIZED TO MEET YOUR SPECIFICATIONS AND ENSURE COMPLIANCE
Designed to Your Exact Needs
Your needs aren’t the same as other oil and gas operations. We work with you to create a customized well isolation tool for your well stimulation treatments. Some of our design considerations include:
WELLHEAD CONNECTION:
Our design will have the required flange or screwhead connection for easy mounting.
FLOW RATE REQUIREMENTS
We’ll design your isolation tool to satisfy the high-pressure flow requirements of your treatment process.
COMPONENT CONFIGURATION
Your system has a unique arrangement, sizes, and pressure ratings that will guide the creation of your tool.
REGULATIONS & COMPLIANCE
We will also consider regulatory requirements applicable to your region to keep you compliant.
Benefits of Wellhead Isolation Tool
01
Helps reduce completion costs and minimize damage to production trees caused by acids, pressures, and erosion.
02
Allows high-pressure treatments to be performed on wells with low-pressure production trees or wellheads, improving efficiency and operational uptime.
03
Reduces operating expenses and production time.
04
Extends the service life of production equipment and eliminates the need for a workover rig or wellhead upgrade for a stimulation job.
05
Enhances the health, safety, and environmental profile by decreasing the risk of exposure to high pressures and abrasive fluids.
TYPES OF WELL ISOLATION TOOLS
Every operation needs a different isolation tool — there is no one-size-fits-all approach. GN offers several types of isolation tools to protect your wellhead during well stimulation treatments. Our isolation tools include:
Dual Cylinder Isolation Tool:
This option is designed with two offset hydraulic cylinders centered over the wellhead. This layout makes dual cylinder tools shorter and more compact. We offer several types of dual cylinder tools with different specifications to meet your precise needs.
Single Cylinder Isolation Tool:
This tool has one cylinder centered directly over the wellhead. This design allows for more flexibility for use with other components. Similarly, there are multiple types of single cylinder tools to select from.
